BCS Data: Dynamic Variation

The Equinox data set contains Beam Characterization System (BCS) videos and image sequences which show the variation in beam pointing due to heliostat oscillations induced by wind. It also includes contemporaneous wind speed and direction data collected from a weather station in the vicinity.

Beam Characterization System (BCS) video

Image of bcs-data-dynamic
Click image to enlarge

Location

  • OpenCSP_Box: OpenCSP_Data/Sandia_BCS_Survey_1
  • OpenCSP_Box: OpenCSP_Data/Sandia_BCS_Survey_1/2022-11-08_FallEquinoxMidWinterSolstice/2_Data/2022-11-08_A

Status

Posted and documented

Documentation

  • R. C. Brost, A. Evans, Kevin Good, Luis Garcia Maldonado. Equinox Data Set Analysis. Sandia National Laboratories presentation SAND2023-09606PE, September 18, 2023.
  • J. W. Strachan. Revisiting the BCS, a Measurement System for Characterizing the Optics of Solar Collectors. Sandia Technical Report SAND92-2789C, 1992.
  • R. C. Brost. Challenges and Solutions in Heliostat Optical Metrology. DOE Heliostat Consortium Seminar presented September 27, 2023.
